Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature

Product Categories

Mianyang Henshin Magnetic Material Co., Ltd.

Contact Now

Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature

Name: Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature
Brand: HSMAG
Price: 1 USD

Wholesale Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature from china suppliers

Brand Name : HSMAG

Model Number : Sm2Co17

Certification : ITAF16949 ISO9001

Place of Origin : China

MOQ : 1PCS

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100000PCS 15Days

Delivery Time : 30 work days

Packaging Details : Cartons, sheet metal shielding packaging

Orientation : Thickness or according to your needs

Size : Customized Magnet Size

Material : Sintered SmCo Magnet

Grade : XG16-XG33EH

Max Working Temperature : 350℃

Tolerance : 0.05mm, 0.05mm ~ 0.1mm

Lead Time : 20 work day

Sample : Free

Contact Now

Permanent Samarium Cobalt Magnet

Products Description

1:5 SmCo Magnet

SmCo1:5 Magnet is also called SmCo5, the highest working can be 250℃. Based on Sm,Co and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.

2:17 SmCo Magnet

SmCo2:17 Magnet is also called Sm2Co17, the highest working can be 350℃.Based on Sm, Co, copper, iron zirconium and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.

	Raw Material Ratio	Energy Density		ReversibleTemp.coefficient
SmCo₅	Sm:Co=1:5	25MGOe		- 0.05% / ℃
Sm₂Co₁₇	Sm:Co=2:17	32 MGOe		- 0.03% / ℃.
Shape:			Ring, Disk, Cube, Loaf, Segment,custom
Process:			Melting, Crushing, Milling, Machining, Sintering, Pressing, Alignment in Magnetic Fisld, Magnetizing.
Core Technologies:			Composition Controlling Technologies Powder Controlling Technologies Mold Design Technologies Crystal particles Ailgnment Technologies Applied magnetic Technologies Magnetization Technologies
Inspection procedure:			Raw material inspection Granularity inspection Green compact inspection Roughcast inspection Magnetic property inspection Dimensions inspection

Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature

Froperties of SmC0 Magnets

Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature

Company Profile

Mianyang Hengxin Magnetic Materials Co., Ltd. was founded in 1999, specializing in the manufacture and development of sintered samarium cobalt permanent magnet materials and devices; after years of development, it has formed a production capacity of 500 tons of samarium cobalt permanent magnet materials per year, and is the main manufacturer of samarium cobalt permanent magnet materials and devices in China.

Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature

Our Certificates

Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature

Factory Tour

Permanent Samarium Cobalt SmCo Magnets Anti Corrosion 350C Working Temperature

Packagig Shipping
